3. Machine Components
16 PNEG-2381 2000 Series U-Trough Bin Sweep Auger Unload System (72' - 78')
Sweep Components (72'-78') Parts List
Ref # Description Ref # Description
1 1/2" x 1-1/2" Bolt 21 Sweep Backplate Adjuster Plate
2 1/2" x 3-1/2" Bolt Grade 8
22 Sweep Brace Mounting Plate
3 5/8" x 1" Bolt with 3/16" Hole 23 Sweep Brace
4 1/2" Flange Nut
24 Center Brace
5 1/2" Flange Nut Grade 5 UNC 25 Sweep Support Wheel Assembly
6 1/2" Flat Washer
26 Sweep Backplate
7 3/16" Drive-In Grease Zerk 27 Sweep Stop
8 M6 x 1.0 Grease Zerk
28 Sweep End Flight
9 6" Wheel with 3/4" bearing 29 Sweep Flight (Available in 6", 7-1/4" and 8")
10 Washer
30 Wood Bushing
11 Bushing 31 Elevator Drive Wheel Fender
15 Elevator Drive Wheel Assembly
32 Elevator Wheel
20 Support Wheel Mounting Plate 33 Chain Reduction Box
To Next Page
