8. Dimensions
50 PNEG-2381 2000 Series U-Trough Bin Sweep Auger Unload System (72' - 78')
Nominal Bin
Diameter
# of Intermediate
Gates
EFG
Distance
Between Gates
Center of Bin to
1
st
Intermediate Gate
Intermediate Gate
Center to Center
Inches MM Inches MM Inches MM
72' 5 62.7 1591.3 98.8 2509 75.2 1909
75' 5 66.3 1682.8 102.4 2600 78.8 2000
78' 5 69.9 1774.2 106.0 2692 82.4 2092
Nominal Bin
Diameter
# of Intermediate
Gates
HIJ
Center of Bin to
Outer Gate
Minimum
Bin Radius
Maximum
Bin Radius
Inches MM Inches MM Inches MM
72' 5 408 10363 417 10592 438 11125
75' 5 426 10820 435 11049 456 11582
78' 5 444 11278 453 11506 474 12040
