Battery Specifications
Model No GSL-5000U/16S GSL-7000U/16S GSL-10000U/16S
Nominal Parameters
Voltage
51.2V 51.2V 51.2V
Capacity
100Ah 150Ah 200Ah
Energy
5.12KwH 7.68KwH 10.24KwH
Dimensions (L x W x H)
680 x480 x180(220)mm 680 x480 x180(220)mm 680x480x180(220)mm
Weight
60.50kg 78.0 kg 105.5kg
Basic Parameters
Life time(25°C)
20 years
Life cycles(80% DOD, 25°C)
6000 Cycles
Storage time / temperature
5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C
Operation temperature
-20°C to 60°C @60+/-25% Relative Humidity
Storage temperature
0°C to 45°C @60+/-25% Relative Humidity
Lithium Battery Standard
IEC62619,UN38.3,ROHS,CE-EMC,UL1642,MSDS
Enclosure protection rating
IP21
Electrical Parameters
Operation voltage
51.2 Vdc 51.2 Vdc 51.2 Vdc
Max. charging voltage
58 Vdc 58 Vdc 58 Vdc
Cut-off Discharge Voltage
44 Vdc 44 V dc 44 Vdc
Max. charging and discharging
current
100A(5120W) 120A(6144W) 120A(6144W)
