GSL TECHNOLOGY GSL5000U - SOC Indicator & Status Indicator Guides

www.gsl-energy.com - 6 -
6 Canbus Canbus Canbus communication port
7 RS485 port RS485 RS485 communication port
8 port Reset button RST For reset the batter
9 Battery Switch On/Off Turn On/Off
10 LED CAPACITY Capacity indicator
11 LED ALM Alarm indicator
12 LED RUN Operation indicator
13 LCD  
14 LCD Key  
15 Handle  
16 Bracket  
3.3.SOC Indicator & Status Indicator Guides
Chart 1: Battery Status
Status
Normal/
Warning/
Protection
RUN ALM Capacity LED
Description
Shut
Down
Shut down OFF OFF OFF OFF OFF OFF All OFF
Standby Normal Flash OFF OFF OFF OFF OFF Standby
Charge
Normal ON OFF
Based on capacity Warning ON Flash
Protection ON ON
Discharge
Normal ON OFF
Based on capacity
Warning ON Flash
Protection OFF ON OFF OFF OFF OFF UVP, OCP
Fault Protection OFF ON OFF OFF OFF OFF
Stop charging
or discharging
