www.gsl-energy.com - 5 -
3.Introduction to the battery
3.1.Key Features
LiFePO4 composition – provides exceptional safety and longevity
High safety and reliability
6,000cycles/20 year service life
Consistent performance over wide temperature range
Wall-mounted, convenient installation
Integrated state-of-the-art BMS to manage and monitor battery information including voltage,
current and temperature as well as balance cell charging/discharging rates
5-10years warranty
3.2.Interface Introduction
This section details the interface functions of front and back panel..
Front interface:
No. Description Silk-screen Remark
1-2 UES0600 P+ P+ Output terminal
3-4 UES0600 P- P- Output terminal
5 Dial switch ADS Set the address
