2.Battery Specifications
Battery Specifications
Model No GSL-5000U/15S GSL-7000U/15S GSL-10000U/15S
Nominal Parameters
Voltage
48 V 48 V 48 V
Capacity
100Ah 150Ah 200Ah
Energy
4.8 KwH 7.2 KwH 9.6 KwH
Dimensions (L x W x H)
680 x480 x180(220)mm 680 x480 x180(220)mm 680x480x180(220)mm
Weight
58.5kg 75.0 kg 96.5kg
Basic Parameters
Life time(25°C)
20 years
Life cycles(80% DOD, 25°C)
6000 Cycles
Storage time / temperature
5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C
Operation temperature
-20°C to 60°C @60+/-25% Relative Humidity
Storage temperature
0°C to 45°C @60+/-25% Relative Humidity
Lithium Battery Standard
IEC62619,UN38.3,ROHS,CE-EMC,UL1642,MSDS
Enclosure protection rating
IP21
Electrical Parameters
Operation voltage
48 Vdc 48 Vdc 48 Vdc
Max. charging voltage
54 Vdc 54 Vdc 54 Vdc
Cut-off Discharge Voltage
42 Vdc 42 Vdc 42 Vdc
Max. charging and discharging
current
100A(4800W) 120A(5760W) 120A(5760W)
