160
PART 2
Applying Frame Protection
138692 Rev 0 (04/22)
Section F.
GT Bicycle Owner’s Manual
Chainstay Protector
On mountain or road bikes, the chainstay
protector is a clear, adhesive film applied to the
upper surface of the right chainstay. This
protector can prevent damage to the chainstay
caused by the chain.
Figure 26.
On mountain bikes, a wrap-around or snap on
type protector (1) can be installed as additional
protection.
1
Figure 26.
