GT Grade - E-Bike Drive System ID

75
PART 2
Drive System Parts E-Bike
Section A. Important Safety Information
GT Bicycle Owner’s Manual
5
1
3
4
2
6
Drive System Parts E-Bike
The example shown below is a E-Bike in the Mountain category. There are many different bkes that have
these same basic drive system comnnents.
1. Drive unit
2. Drive Controls/Display
3. Internal Battery
4. Charge port
5. Wheel Sensor
6. Serial number
Identification
