F320 Instruction Manual 7
rev 03.26.13
PROGRAMMING OPTIONS
Select Forced Entry Output Default: Output #3
Sets which output activates if the Door Sense input opens
before access is granted. This output is not timed.
Press: 1 1 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Alarm Shunt Output Default: No Output
Sets which output activates during the time access is
granted. (Use this output to shunt alarm contacts attached
to the access door.) This output may be timed or latched.
Press: 1 5 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3,
4 = Output #4 0 = No Output
Select Request-to-Enter Output Default: Relay #1
Sets which output activates when the Request-to-Enter
input is grounded. This output remains activated for at least
the length of time specied by the On-times for the relays
or outputs. If the Request-to-Enter input continues to be
grounded beyond the time specied by the On-times for
the relays or outputs, the output will remain activated as
long as the Request-to-Enter input remains grounded.
Press: 1 6 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Relay #1 On-time Default: 2 Seconds
Sets the length of time Relay #1 activates when triggered.
Press: 2 1 # Seconds #
Seconds = Output time in seconds (0-60)
Relay #2 On-time Default: 2 Seconds
Sets the length of time Relay #2 activates when triggered.
Press: 2 2 # Seconds #
Seconds = Output time in seconds (0-60)
Solid-state Output #3 On-time Default: 2 Seconds
Sets the length of time Output #3 activates when triggered.
Press: 2 3 # Seconds #
Seconds = Output time in seconds (0-60) 99 = Toggle mode
Solid-state Output #4 On-time Default: 2 Seconds
Sets the length of time Output #4 activates when triggered.
Press: 2 4 # Seconds #
Seconds = Output time in seconds (0-60) 99 = Toggle mode
Set Downlight On-Time Default: 2 Minutes
Sets the time duration that the downlight remains on after
a key press.
Press: 2 5 # Duration #
0 = Always o 1 = 1 minute 2 = 2 minutes 3 = 3 minutes
4 = 4 minutes 99 = Always on
Select Door Ajar Output Default: Output #4
Sets which output activates if the Door Sense input stays
open after access is granted. This output is not timed.
Press: 1 2 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Keypad Lockout Output Default: No Output
Sets which output activates when the keypad is “locked out”
after toomany incorrect entry code attempts. The lockout
time is 60 seconds.
Press: 1 3 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Keypad Active Output Default: No Output
Sets which output activates when any keys are pressed. This
output is timed.
Press: 1 4 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Door Sense or Inhibit Input Default: Door Sense
The input on terminal block J4, terminal #3 can be
programmed for DOOR SENSE or INHIBIT.
Press: 1 0 # Input#
Input = 1 for Inhibit,
= 0 for Door Sense
When programmed for DOOR SENSE, if an open condition
on the input occurs before access is granted (with an entry
code or with the request-to-enter input) a FORCED ENTRY
output will occur. If an open condition remains 60 seconds
after
a relay activation for access, a DOOR AJAR output will occur.
When programmed for INHIBIT, a closed condition on the input
will prevent relay #1 from activating when access is requested
(with an entry code). This mode is typically used with an
external timer to disable the access device at certain times.
