5.04 Trouble Shooting
If the DH 2000 does not react when pressing the keys of the hand con-
trol ?
Check that the plug for the hand control is correctly inserted
If the green light on the bottom of the DH 2000 does not come on when
pressing the keys of the hand control ?
Check that the emergency stop is not activated
Check that the batteries are charged
Check that the charger is on
the hand control could be faulty or a fuse is blown in the hoist
Please contact your local Guldmann representative
If the green light on the bottom of the DH 2000 is still ashing after the
hoist has been recharged ?
Check that the light on the charger is on when recharging the DH 2000
Check that the charger is on
Check that the charging points of the DH 2000 have been connected properly
to the charging station
Please contact your local Guldmann representative
6.00 Technical Specications
Dimension (WxHxL): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350x190x245 mm
Maximum lifting capacity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 kg
No. of lifts per charging: . . . . . . . . . . . . . . . . . 100 with 85 kg & 40 with 175 kg
Lifting speed with 85 kg load: . . . . . . . . . . . . . . . . . . . . . . . .2000 mm pr. min.
Lifting interval: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2000 mm
Min. distance from pivot joint on the lifting hanger to the ceiling: . . . . 400 mm
Max. distance from pivot joint on the lifting hanger to the ceiling:. . . 2400 mm
Total weight of hoist without sling:
without hanger: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14,5 kg
Lifting hanger: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2,0 kg
Electrical connection for charger / hoist: . . . . . . . . . . . . . . . . . . . . 230V / 115V
(depending on national voltage standards)
Connection between charger and hoist: . . . . . . . . . . . . . . . . . . . . . . . 24V DC.
Consumption / effect of actuator: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240 VA.
Charger, fully automatic: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24V DC / 0,5 Ah.
Charging time: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 8 hours
Batteries, gasproof and free of maintenance: . . . . . . . . . . 2 pcs 12V / 4,0 Ah
Battery protection at too low a voltage: . . . . . . . . Yes, disconnects below 17V
Permitted periodic load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15/85
(working time / breaks in percentages)
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 year
•
•
•
•
•
•
•
•
•
•
