GW Instek ASR-2000 Series Quick Start Guide

11
Accuracy
*2
±(0.5 % of set + 0.6 V / 1.2 V)
Output phase
Single phase, Two-wire
Maximum
current
*3
100 V
5 A
10 A
200 V
2.5 A
5 A
Maximum
peak current
*4
100 V
20 A
40 A
200 V
10 A
20 A
Load power factor
0 to 1 (leading phase or lagging phase)
Power capacity
500 VA
1000 VA
Frequency
Setting range
AC Mode: 40.00 Hz to 999.9 Hz, AC+DC
Mode: 1.00 Hz to 999.9 Hz
Setting
resolution
0.01 Hz (1.00 to 99.99 Hz), 0.1 Hz (100.0
to 999.9 Hz)
Accuracy
For 45 Hz to 65 Hz: 0.01% of set
For 1 Hz to 999.9 Hz: 0.02% of set
Stability
*5
± 0.005%
Output on/off phase
0.0° to 359.9° variable (setting resolution
0.1°)
DC offset
*6
Within ± 20 mV (TYP)
*1
100 V / 200 V range
*2
For an output voltage of 17.5 V to 175 V / 35 V to 350 V, sine wave, an
output frequency of 45 Hz to 65 Hz, no load, DC voltage setting 0V
(AC+DC mode) and 23°C ± 5°C
*3
For an output voltage of 1 V to 100 V / 2 V to 200 V. Limited by the
power capacity when the output voltage is 100 V to 175 V / 200 V to 350
V. If there is the DC superimposition, the current of AC+DC mode
satisfies the maximum current. In the case of lower than 40 Hz, and the
ambient temperature is 40°C or higher, the maximum current will be
decrease.
