GW Instek ASR-2000 Series Quick Start Guide

12
*4
With respect to the capacitor-input rectifying load. Limited by the
maximum current.
*5
For 45 Hz to 65 Hz, the rated output voltage, no load and the resistance
load for the maximum current, and the operating temperature.
*6
In the case of the AC mode and output voltage setting to 0 V.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Output rating for DC mode
Voltage
Setting Range
*1
-250.0 V to +250.0 V / -500.0 V to
+500.0 V
Setting Resolution
0.1 V
Accuracy
*2
±(|0.5 % of set| + 0.6 V / 1.2 V)
Maximum
current
*3
100 V
5 A
10 A
200 V
2.5 A
5 A
Maximum peak
current
*4
100 V
20 A
40 A
200 V
10 A
20 A
Power capacity
500 W
1000 W
*1
100 V / 200 V range
*2
For an output voltage of -250 V to -25 V, +25 V to +250 V / -500 V to -50
V, +50 V to +500 V, no load, AC voltage setting 0V (AC+DC mode) and
23°C ± 5°C
*3
For an output voltage of 1.4 V to 100 V / 2.8 V to 200 V. Limited by the
power capacity when the output voltage is 100 V to 250 V / 200 V to 500
V.
*4
Within 5 ms, Limited by the maximum current.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Output voltage stability
Line regulation
*1
±0.2% or less
