GW Instek ASR-2000 Series Quick Start Guide

13
Load regulation
*2
±0.15% @45 - 65Hz
±0.5% @DC, all other frequencies
(0 to 100%, via output terminal)
Ripple noise
*3
0.7 Vrms / 1.4 Vrms (TYP)
*1
Power source input voltage is 100 V, 120 V, or 230 V, no load, rated
output.
*2
For an output voltage of 75 V to 175 V / 150 V to 350 V, a load power
factor of 1, stepwise change from an output current of 0 A to maximum
current (or its reverse), using the output terminal on the rear panel.
*3
For 5 Hz to 1 MHz components in DC mode using the output terminal on
the rear panel.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Output voltage waveform distortion ratio, Output voltage response time,
Efficiency
Total harmonic distortion (THD)
*1
<0.2 % @50/60 Hz
<0.3 % @<500 Hz
<0.5 % @500.1 Hz to 999.9 Hz
Output voltage response time
*2
100 s (TYP)
Efficiency
*3
70 % or more
*1
At an output voltage of 50 V to 175 V / 100 V to 350 V, a load power
factor of 1, and in AC and AC+DC mode.
*2
For an output voltage of 100 V / 200 V, a load power factor of 1, with
respect to stepwise change from an output current of 0 A to the
maximum current (or its reverse). 10% ~ 90% of output voltage
*3
For AC mode, at an output voltage of 100 V / 200 V, maximum current,
and load power factor of 1 and sine wave only.
μ
