14
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Measured value display
Note:
All accuracy of the measurement function is indicated for 23 °C±5
°C.
Voltage
RMS, AVG
value
*1
Resolution
0.1 V
Accuracy
*2
For 45 Hz to 65 Hz and DC: ±(0.5 % of
reading + 0.3 V / 0.6 V)
For 40 Hz to 999.9 Hz: ±(0.7 % of
reading + 0.9 V / 1.8 V)
PEAK value
Resolution
0.1 V
Accuracy
For 45 Hz to 65 Hz and DC: ±(|2 % of
reading| + 1 V / 2 V)
Current
RMS, AVG
value
Resolution
0.01 A
Accuracy
*3
For 45 Hz to 65 Hz
and DC:
±(0.5 % of reading
+ 0.02 A / 0.02 A)
For 40 Hz to 999.9
Hz:
±(0.7 % of reading
+ 0.04 A / 0.04 A)
For 45 Hz to 65 Hz
and DC:
±(0.5 % of reading
+ 0.04 A / 0.02 A)
For 40 Hz to 999.9
Hz:
±(0.7 % of reading
+ 0.08 A / 0.04 A)
PEAK value
Resolution
0.01 A
Accuracy
*4
For 45 Hz to 65 Hz
and DC:
±(|2 % of reading|
+ 0.2 A / 0.1 A)
For 45 Hz to 65 Hz
and DC:
±(|2 % of reading|
+ 0.2 A / 0.1 A)
Power
Active (W)
Resolution
0.1 / 1 W
Accuracy
*5
±(2 % of reading +
0.5 W)
±(2 % of reading +
1 W)
