15
Apparent
(VA)
Resolution
0.1 / 1 VA
Accuracy
*5*6
±(2 % of reading +
0.5 VA)
±(2 % of reading +
1 VA)
Reactive
(VAR)
Resolution
0.1 / 1 VAR
Accuracy
*5*7
±(2 % of reading +
0.5 VAR)
±(2 % of reading +
1 VAR)
Load power factor
Range
0.000 to 1.000
Resolution
0.001
Load crest factor
Range
0.00 to 50.00
Resolution
0.01
Harmonic voltage
Effective value (rms)
Percent (%)
(AC-INT and 50/60 Hz
only)
Range
Up to 100th order of the fundamental
wave
Full Scale
175 V / 350 V, 100%
Resolution
0.1 V, 0.1%
Accuracy
*8
Up to 20th ±(0.2 % of reading + 0.5 V /
1 V)
20th to 100th ±
(0.3 % of reading + 0.5 V / 1 V)
Harmonic current
Effective value (rms)
Percent (%)
(AC-INT and 50/60 Hz
only)
Range
Up to 100th order of the fundamental
wave
Full Scale
5 A / 2.5 A, 100%
10 A / 5 A, 100%
Resolution
0.01 A, 0.1%
Accuracy
*3
Up to 20th
±(1 % of reading +
0.1 A / 0.05 A)
20th to 100th
±(1.5 % of reading
+ 0.1 A / 0.05 A)
Up to 20th
±(1 % of reading +
0.2 A / 0.1 A)
20th to 100th
±(1.5 % of reading
+ 0.2 A / 0.1 A)
