4. PANEL INTRODUCTION
After the instrument is switched on, all the important settings are displayed
in the readout. The LED’s located on the front panel assist operation and
indicate additional information. Incorrect operation and the electrical end
positions of control knobs are indicated by a warning beep.
Except the Power pushbutton (POWER), the Focus control (FOCUS), and
the Trace Rotation control, all other controls are electronically selected,
and their functions and settings can therefore be stored.
The front panel is subdivided into six sections:
z Display controls
z Vertical controls
z Horizontal controls
z Trigger controls
z Measurement control
z Input connectors
GOS-6112 OSCILLOSCOPE
USER MANUAL
 10 
Front panel of GOS-6112
