GW Instek GPT-9000 series Quick Start Guide

OPERATION
17
Choose the Test Function (MANU mode only)
 Choose the test function by pressing the
corresponding ACW, DCW, IR or GB soft-key.
 The chosen function will be highlighted.
A CW
(Example)
Set the Test Voltage/Current (MANU mode only)
 Use the UP/DOWN arrow keys to bring the cursor to
the Test voltage/Current.
 Use the scroll wheel to set the voltage/current.
Choose HI/LO SET limits (MANU mode only)
 Press the HI/LO soft-key or use the UP/DOWN
arrow keys to choose either HI or LO SET.
 Use the scroll wheel to edit the setting.
I / LH O
OR
Ramp Time (MANU mode only)
 Use the UP/DOWN arrow keys to bring the cursor to
Ramp time.
 Use the scroll wheel to set the ramp time.
 ACW, DCW and IR only
