GW Instek GPT-9801

OPERATION
71
3. The READY indicator will be lit
blue in the READY status.
READY
I R G B
m A
A CW D CW
E
F R E Q = 0 H z 6
0 100
k V
AER
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
D
MM A UN N A_2M A N U = * * * - 0 0
READY status
Y
Note
The buzzer will only sound if Fail Sound is set to
ON. See page 99 for details.
FAIL Timing
Diagrams
The timing diagrams below show the ACW, DCW,
IR and GB timing for the START status, TEST
status and FAIL judgment.
ACW FAIL Timing
START
TEST
FAIL
Discharge time
Output V
time
Initial time
RAMP
TEST TIME
(Approximately 150ms)
DCW FAIL Timing
FAIL
Discharge time
Output V
time
Initial time
RAMP
START
TEST
TEST TIME
(Approximately 150ms)
