GPT-9000/9000A Series User Manual
94
To exit testing, press the
MANU/AUTO key when the
tester is in the READY status. The
tester will revert to the VIEW
status for the current automatic
test.
I R G B A CW D CW
E
F R E Q = 0 H z 6
0
100
k V
EIV
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
W
MA U OT N A_0A U T O = 0 0 1 - 1 0
m A
If all the test steps are allowed to run to
completion (the AUTO test is not stopped or a
protection setting is not tripped) then the tester
will judge each step as either PASS or FAIL.
This is shown as a table after the automatic test
has finished running. If the test has been
stopped, then any remaining tests will not be
run and thus the AUTO test will not finish
running.
P A S
P A S
S
S
P A S
S K I
S
P
E MA U OT N A_ 1A U T O = 0 0 1 - 0 0
# 0 1 : # 0 2 : # 0 3 : # 0 4 : P A S
# 0 5 : # 0 6 : # 0 7 : # 0 8 : S T O
# 0 9 : # 1 0 : # 1 1 : # 1 2 :
# 1 3 : # 1 4 : # 1 5 : # 1 6 :
S
P
F A I
F A I
L
L
FAIL judgment
PASS judgment
skipped step step stopped
The PASS/FAIL judgment for an automatic test
as a whole depends on the results of all the
steps (manual tests) that compose the automatic
test:
Each step must be passed for a PASS judgment
