GPT-9000/9000A Series User Manual

166

I ERR

For ACW, DCW tests. Shown when the current

is set too high.

SHORT

Voltage is too low or there is no High Voltage

output. Indicates that the DUT could be

shorted.

V ERR

For ACW, DCW tests. Indicates that an

abnormal voltage has been detected.

V = 0

For GB tests. Voltage is equal to 0. Check to

see that the SENSE H or SOURCE H is not

open.

R ERR

For IR tests. The voltage is too high or

resistance=0Ω. Check to see whether the DUT

or test lead is shorting.

For GB tests. The resistance is too high.

I<SET

For GB tests. Current too low. Indicates that

the SOURCE L or SOURCE H test lead is open

or poorly connected. Test the test lead

connection with the DUT to confirm.

I>SET

For GB tests. Current is too high.

R=0

For GB tests. Resistance = 0. This error

indicates that there is an error with the

measured resistance (0Ω). Perform the zeroing

function again.

GBV OVER

GBV > 5.4V
