GPT-9000/9000A Series User Manual
38
ACW, DCW, IR and GB Manual Testing
This section describes how to create, edit and run a single ACW,
DCW, IR or GB safety test. Each Manual setting described in this
chapter only applies to the selected manual test – no other manual tests
are affected.
Each manual test can be stored/recalled to/from one of 100
memory locations. Each stored manual test can be used as a test
step when creating an AUTO test (page 81).
 Choose/Recall a Manual Test number → from page 39.
 Edit Manual Test Settings → from page 40.
 Setting the Test Function→ from page 41.
 Setting the Test Voltage or Test Current→ from page 42.
 Setting the Test Frequency → from page 43.
 Setting the Upper and Lower Limits → from page 44.
 Setting a Reference Value → from page 46.
 Setting the Test Time (Timer) → from page 47.
 Setting the Ramp Up Time → from page 50.
 Creating a MANU Test File Name→ from page 51.
 Setting the ARC Mode → from page 52.
 Setting PASS HOLD→ from page 55.
 Setting FAIL MODE→ from page 56.
 Setting MAX HOLD→ from page 57.
 Setting the Grounding Mode → from page 58.
 Saving and Exiting EDIT Status→ from page 63.
 Running a MANU Test → from page 64.
 PASS / FAIL MANU Test → from page 68.
 Zeroing of the Test Leads (GB only) → from page 73
 Special MANU Test Mode (000) → from page 76
Before operating the GPT-9000/9000A please read the safety
precautions as outlined in the Set Up chapter on page 23.
