LCR-800 Series User Manual
6
This line can display the measured Quality Factor or Dissipation or ESR or
EPR.
(23). Instrument status or indicates measurement results based on entered test
limits.
(24). Test conditions
(25). Input terminals
BNC connectors, connects to device under test (DUT).
Connectors of the LCR Meters
BIAS
Lforce (current, low)

Lsense (potential low)

Hsense (potential high)

Hforce (current, high)

