22/01/2015
MADE in PRC
- EN 60335-2-29
CT 160
µc
EFFICACE
/ RMS
Moyen/Average
(EN 60335)
50-60hz
Reg 1 Reg 2 fuse
cm kg
230V 190W
12V 2 13.5A
7A 9A
15A 20.5x30x13.5 3.9
24V 2 7.5A
3A 5A
W
W
ex.
Battery 12V
BATTERY
CHARGER
12-24V
Ref. 024106
This traditionnal battery charger can charge 12V and 24V lead-acid or calcium batteries for
small cars, vans and agricultural vehicles.
• Copper wound transformer
• Clamp cables 1.5m
• Power supply cable 1.3m
• Thermal protection of the transformer
• Protection against polarity reversal with a 15A automotive fuse at the front.
• Isolated clamps
• Metallic casing
GENERAL PROTECTION
TECHNOLOGY
www.gys.fr
• To charge lead acid batteries with liquid electrolyte:
- 12V: from 25 to 160 Ah
- 24V: from 15 to 90 Ah
• Ammeter to indicate the charge
• 2 charge speeds: Normal and “Boost”.

Table of Contents

Other manuals for GYS CT 160

Preview: Manual
Manual36 pages
Preview: Instruction Manual
Instruction Manual8 pages

Questions and Answers

  • K
    Kelsey BatesAug 18, 2025
    What to do if my GYS CT 160 is properly connected but it does not charge the battery?
    • T
      thomas57Aug 18, 2025
      If your GYS Battery Charger is properly connected but isn't charging the battery, several factors could be at play. It might be due to a blown fuse, in which case you should replace it with a new one. Another reason could be bad clamp connections; ensure you clean the terminals and clamps, and also check the condition of the cables and clamps. Also, verify that the selected voltage matches the battery voltage, as wrong charge settings can prevent charging. Finally, after intensive use, the device may have entered thermal protection mode, so allow it to cool down for about 15 minutes.
  • J
    joshua89Aug 20, 2025
    Why does the GYS CT 160's ammeter not fluctuate?
    • A
      Alexis LunaAug 21, 2025
      If the ammeter on your GYS Battery Charger isn't fluctuating, there could be several reasons. First, check your mains power supply, as there might be a power supply problem. Also, inspect the clamps to ensure they are not in short circuit or with reversed polarity; verify that the fuses haven't melted and the circuit breaker hasn't tripped. The battery you're trying to charge might be faulty; check the terminals' voltage with a voltmeter. If the voltage jumps to 2.5V per element instantaneously, the battery could be sulfated or damaged. Ensure the voltage switch is on the correct setting (12 or 24V). Finally, if the device has been used intensively, it may have entered thermal protection mode; wait 15 minutes for it to cool down.
  • M
    Mario NelsonAug 23, 2025
    What to do if the fuse blows every time it is replaced on my GYS CT 160 Battery Charger?
    • J
      Jean Smith MDAug 23, 2025
      If the fuse in your GYS Battery Charger blows every time it's replaced, consider these possibilities: Check for polarity reversal by ensuring the (+) clamp is connected to the battery's (+) terminal and the (-) clamp to the battery's (-) terminal. Avoid starting the vehicle while the charger is connected. Ensure the selected voltage matches the battery voltage. Do not draw any current from the battery during charging. Confirm that the machine is not charging a 12V battery in 24V mode; if so, set the switch to 12V.
  • A
    Ashley MartinezAug 26, 2025
    What to do if the ammeter's pin goes above the maximum marking while the GYS CT 160 is set to minimum intensity?
    • D
      Daniel ReynoldsAug 26, 2025
      If the ammeter's pin goes above the maximum marking while your GYS Battery Charger is set to minimum intensity, it could be due to a deeply discharged battery; continue charging using the minimum setting. Also, check that the switch is on the right setting (12 or 24V). Finally, your battery may have elements in short circuit, indicating a damaged battery that needs replacement.
  • J
    Joseph BishopAug 27, 2025
    How to fix a GYS Battery Charger when the ON/OFF button does not switch on?
    • N
      Nicole LeeAug 27, 2025
      If the ON/OFF button on your GYS Battery Charger doesn't switch on when set to ON, the issue might be due to no mains voltage. Check that the power cord is properly plugged into a 230V 50/60Hz socket and verify the power supply network.
  • F
    Frank ReidAug 30, 2025
    What to do if GYS CT 160 is properly connected but it does not charge the battery?
    • W
      William HardingAug 30, 2025
      If your GYS Battery Charger is connected but not charging, there might be several reasons. First, check the fuse and replace it if it's blown. Then, clean the terminals and clamps to ensure good connections, and inspect the cables and clamps for damage. Also, verify that the selected voltage matches the battery voltage. If the device has been used intensively, it may have entered thermal protection mode; wait 15 minutes for it to cool down.
  • A
    Ashley HarringtonSep 1, 2025
    Why GYS CT 160's ammeter does not fluctuate?
    • T
      Travis RodriguezSep 1, 2025
      If the ammeter on your GYS Battery Charger isn't fluctuating, it could be due to several reasons. There might be a power supply problem, so check your mains power supply. Also, check for short-circuited clamps or polarity reversal, and ensure the fuses haven't melted and the circuit breaker isn't tripped. The battery you're trying to charge could be faulty; test the terminals' voltage with a voltmeter – if it jumps to 2.5V per element instantaneously, the battery may be sulfated or damaged. Verify the voltage setting (12/24V) is correct. Finally, if the device was used intensively, it may be in thermal protection mode; wait 15 minutes for it to cool down.
  • N
    Nancy PetersenSep 3, 2025
    What to do if the fuse blows every time it is replaced on GYS CT 160 Battery Charger?
    • J
      Julie JohnsonSep 4, 2025
      If the fuse in your GYS Battery Charger blows repeatedly, it could be due to a few reasons. Ensure you've connected the clamps with the correct polarity (+ to + and - to -). Avoid starting the vehicle while the charger is connected. Verify that the selected voltage matches the battery voltage. Avoid drawing any current from the battery during charging. Also, make sure you are not charging a 12V battery in 24V mode; set the switch to 12V if necessary.
  • T
    Tony SmithSep 6, 2025
    What to do if ammeter's pin goes above the maximum marking on GYS CT 160?
    • K
      kathybensonSep 6, 2025
      If the ammeter pin goes above the maximum marking on your GYS Battery Charger while set to minimum intensity, it could be because the battery is deeply discharged; continue charging using the minimum setting. Verify that the voltage setting (12/24V) is correct. Alternatively, your battery may have elements in short circuit, which indicates a damaged battery that needs replacement.
  • B
    Brian ClarkSep 8, 2025
    How to fix GYS CT 160 Battery Charger when the ON/OFF button does not switch on?
    • S
      Sarah HammondSep 8, 2025
      If the ON/OFF button on your GYS Battery Charger doesn't switch on, check that the power cord is plugged into a 230V 50/60Hz socket and verify the power supply network.

GYS CT 160 Specifications

General IconGeneral
Fuse16 A
Protection classIP21
Dimensions30 x 12 x 23.5 cm
Weight4.7 kg
Mains voltage230 V
Input voltage230 V
