Page #10 background image
10
Figure 10 S24-U front panel
Figure 11 S24G-U front panel
(1) Power LED (Power)
(2) 10/100/1000Base-T copper port status LED
(3) Uplink port status LED
(4) 10/100Base-TX copper port status LED
(5) PoE status LED (6) PoE-MAX LED
(7) 10/100/1000Base-T copper port (8) DIP switch
(9) 10/100Base-TX copper port
7 8 12
