11
NOTE:
The three-position DIP switch can shift the switch functions as
follows:
• 标准交换—Enable flow control and downshift.
• 网络克隆—Disable flow control and enable downshift.
• 汇聚上联—Enable flow control, downshift, and uplink port
aggregation. (Ports 15 and 16 on the S16G-U and ports 23
and 24 on the S24G-U are uplink ports.)
Rear panel
Figure 12 S8G-U rear panel
Figure 13 S9-PWR rear panel
