H3C Mini Series User Manual

16
LED Status Description
10/100
Base-TX
copper port
status LED
(Link/Act)
Steady
green
A 10/100-Mbps link is present.
Flashing
green
The port is receiving or sending
data at 10/100 Mbps.
Off No link is present.
10/100/1000B
ase-T copper
port status
LED
(Link/Act)
Steady
green
A 1000-Mbps link is present.
Flashing
green
The port is receiving or sending
data at 1000 Mbps.
Steady
yellow
A 10/100-Mbps link is present.
Flashing
yellow
The port is receiving or sending
data at 10/100 Mbps.
Off No link is present.
PoE-MAX
LED on the
S9-PWR
switch
Steady
yellow
The switch PoE power is in the
protection range 58 W to 64 W.
Off
The switch PoE power does not
reach the protection range
PoE status
LED on the
S9-PWR
switch
Steady
yellow
Normal PoE power supply.
Flashing
yellow
Abnormal PoE power supply.
Off No PoE power supply.
