Connecting a power adapter
The S8G-U and S9-PWR switches support power input by using a
power adapter.
To connect the power adapter:
1. Connect the power cord to the power adapter.
This step is not required for an S8G-U switch.
2. Connect the DC connector of the power adapter to the DC
power receptacle on the switch.
3. Connect the plug of the power adapter to an AC power source.
Figure 6 Connecting a power adapter
1
23
