SIC-1VE1 45
Step 2: Check the status of LINK LED on the GEC panel: ON means the link is
connected and OFF means the link is not connected. In the latter case, check the
line.
SIC-1VE1
Introduction 1-port E1 voice interface card (SIC-1VE1) can handle dense voice signals in VoIP
system. It provides a CE1/PRI/R2 port, allowing the access of 30 channels of voice
signals.
n
■ When purchasing a SIC-1VE1 interface card, users should purchase a VCPM
and configure a VPM based on voice traffic.
■ No VCPM is required, but only a VPM needs to be installed on the main board
when MSR 20-1x series routers need to be equipped with a SIC-1VE1 interface
card.
■ VCPM and VPM need to be installed on the main board when MSR 30 series
routers need to be equipped with a SIC-1VE1 interface card.
■ VCPM and VPM need to be installed on the MSCA card when MSR 50 series
routers need to be equipped with a SIC-1VE1 interface card.
Interface Attributes
DIP Switches CE1/PRI/R2 interface is compatible with 75-ohm and 120-ohm impedance.
Matching of different impedance is implemented through an 8BIT DIP switch. By
default, all the DIP switches are set to ON, as illustrated in the following figure:
Table 20 Interface Attributes of the SIC-1VE1
Attribute Description
Connector DB 15
Number of connector 1
Interface standard G.703, G.704
Interface rate 2.048 Mbps
Frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Cable type 75-ohm non-balanced coaxial cable
120-ohm balanced twisted pair cable
Coaxial connector, network interface
connector and 75-ohm to 120-ohm
adapter (with BNC connector)
Operation mode CE1
ISDN PRI (only supported by SIC-1VE1)
R2
Services Backup
Terminal access
ISDN (only supported by SIC-1VE1)
