H3C S1016/1024 Ethernet Switch
Chapter 1 Product Overvie
w
1-3
Table 1-2 Features of S1016/1024
Features Description
Wire-speed Layer 2
switching
All ports support wire-speed forwarding.
All ports are in the same broadcast domain.
Switching mode Store and forward
MAC address table
Address auto-learning and auto-aging (with
aging time 300 seconds)
Maximum MAC address entries: 8K
1.3 Hardware Description
1.3.1 Product Appearance
I. Front panel
The power LED, port LEDs and 16/24 (S1016/1024)
10/100Base-TX Ethernet ports are arranged in order on the front
panel of the S1016/1024, as shown in
Figure 1-1 and Figure 1-2
respectively.
Figure 1-1 Front view of S1016
