H3C S6520X-SI Series

56
Item
S6520X-16ST-
SI
S6520X-24ST-
SI
S6520X-18C
-SI
S6520X-26C
-SI
S6520X-26
MC-SI
{ Max voltage range: 90 to 290 VAC @ 47 to 63 Hz
• High-voltage DC input
{ Rated voltage range: 240 VDC
{ Max voltage range: 180 to 320 VDC
PSR150-A1:
• Rated voltage range: 100 to 240 VAC @ 50/60 Hz
• Max voltage range: 90 to 264 VAC @ 47 to 63 Hz
PSR150-D1:
You can use a –48 VDC power source in the equipment room or an H3C RPS (RPS800-A
or RPS1600-A) for the PSR150-D1 power module.
• Rated voltage range: –48 VDC to –60 VDC
• Max voltage range: –36 VDC to –72 VDC
Typical power
consumption
(30% flow,
tested as
required by
CQC)
41 W 51 W 51 W 64 W 97 W
Maximum
power
consumption
(100% flow, and
fans at full
speed)
59 W 73 W 97 W 113 W 134 W
Chassis
leakage current
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943.1
Melting current
of power
module fuse
• PSR75-12A: 3.15 A/250 V (not supported on S6520X-26MC-SI)
• PSR150-A1: 6.3 A/250 V
• PSR150-D1: 8 A/250 V
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Humidity 5% RH to 95% RH, noncondensing
Fire resistance
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943.1
Table 10 Technical specifications of non-PoE switches (2)
Item S6520X-10XT-SI S6520X-16XT-SI
Dimensions (H ×
W × D)
43.6 × 440 × 260 mm (1.72 × 17.32 × 10.24
in)
43.6 × 440 × 260 mm (1.72 × 17.32 ×
10.24 in)
Weight ≤ 5 kg (11.02 lb) ≤ 5 kg (11.02 lb)
Console port
• 1 × micro USB console port
• 1 × serial console port
Only the micro USB console port is
available when you connect both ports.
• 1 × micro USB console port
• 1 × serial console port
Only the micro USB console port is
available when you connect both ports.
USB port 1 1
Management
1 1
