H3C S6850-56HF Configuration Guide

26
LLDP status information of port 2 [Twenty-FiveGigE1/0/2]:
LLDP agent nearest-bridge:
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No
MED trap flag : No
Polling interval : 0s
Number of LLDP neighbors : 0
Number of MED neighbors : 0
Number of CDP neighbors : 0
Number of sent optional TLV : 0
Number of received unknown TLV : 0
LLDP agent nearest-nontpmr:
Port status of LLDP : Enable
Admin status : Disable
Trap flag : No
MED trap flag : No
Polling interval : 0s
Number of LLDP neighbors : 0
Number of MED neighbors : 0
Number of CDP neighbors : 0
Number of sent optional TLV : 1
Number of received unknown TLV : 0
LLDP agent nearest-customer:
Port status of LLDP : Enable
Admin status : Disable
Trap flag : No
MED trap flag : No
Polling interval : 0s
Number of LLDP neighbors : 0
Number of MED neighbors : 0
Number of CDP neighbors : 0
Number of sent optional TLV : 16
Number of received unknown TLV : 0
Example: Configuring CDP-compatible LLDP
Network configuration
As shown in Figure 6, Twenty-FiveGigE 1/0/1 and Twenty-FiveGigE 1/0/2 of Switch A are each
connected to a Cisco IP phone, which sends tagged voice traffic.
Configure voice VLAN 2 on Switch A. Enable CDP compatibility of LLDP on Switch A to allow the
Cisco IP phones to automatically configure the voice VLAN. The voice VLAN feature performs the
following operations:
• Confines the voice traffic to the voice VLAN.
• Isolates the voice traffic from other types of traffic.

H3C S6850-56HF Specifications

General

Model	H3C S6850-56HF
Switch Type	Data Center Switch
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Power Supply	Dual redundant power supplies
Dimensions (W x D x H)	440 x 420 x 43.6 mm
