28
Figure 49 Storage controller configuration screen
2. On the screen as shown in Figure 50, select Manage Volume and press Enter. For more
information about the parameters, see Table 4.
Figure 50 Selecting Manage Volume
Table 4 RAID parameters
Parameter
Description
Volume RAID serial number.
Identifier RAID identifier.
Type RAID level.
Status Current RAID status.
Task
Current RAID task. No background task is in progress for the RAID if
this field displays
None
.
Manage Volume You can select this item and press
Enter
to manage the RAID.
Alt+N
If two RAID arrays exist, you can press
Alt+N
to switch the RAID
array for information displaying.
