1-5
LED Color QTY Meaning
10/100M
(Ethernet
interface
LED)
Yellow 1
Displays the status of the Ethernet
interface:
z On: The Ethernet interface is in
the link-up state.
z Off: The Ethernet interface is in
the link-down state.
z Blinking: Data is being
transmitted or received at
10/100 Mbps.
1000M
(Ethernet
interface
LED)
Green 1
Displays the status of the 1000 M
Ethernet interface:
z On: The Ethernet interface is in
the link-up state.
z Off: The Ethernet interface is in
the link-down state.
z Blinking: Data is being
transmitted or received at 1000
Mbps.
Interfaces
The WA2600 series provide the following interfaces:
z 2.4 GHz or 5 GHz antenna interfaces
z A console interface
z An Ethernet copper interface
z A power supply interface
