H3C WA2600 Enhanced Series Installation Manual

3-5
Installing the AP on the Wall-Mounting Bracket
The installation procedure is the same for both the WA2610E-AGN
and WA2620E-AGN. The WA2610E-AGN is taken as an example in
this manual.
1) Align the AP with the hooks on the wall-mounting bracket and
hang the AP on the bracket. See (1) in
Figure 3-4.
2) Press the AP downward to fix it. See (2) in
Figure 3-4.
