3-9
z In the PoE mode, you do not need to connect the power interface
to a power source. You only need to connect one end of an
Ethernet cable to the Ethernet interface of the AP and the other
end to an Ethernet interface of the PoE-capable device (for
example, an Ethernet switch).
z Identify the silkscreen on the device to avoid taking the console
interface for the Ethernet interface, or vice versa.
z The WA2620E-AGN supports only non-standard PoE power
supply.
Connecting the AP to the Network
The WA2600 series can access the Internet or MAN through the
Ethernet uplink interface. Connect the Ethernet interface of the AP to
an Ethernet interface of an Ethernet switch to implement Internet or
MAN access, as shown in
Figure 3-8.
Figure 3-8 Connect the AP to the network
