ES0205l 12-00
11
INSTALLATION R ECOMMENDATIONS
NOTE: These Installation Recommendations are to be used in conjunction with those
in the Operators Manual. Material supplied here is given specifically for the
Mini Mill.
Machine Coolant (if equipped)
The Mini Mill coolant reservoir has a capacity of 24 gallons. The coolant reservoir can be filled in two
different locations:
The base has cutouts in the right and left sides. Coolant can be filled through these cutouts.
With power removed from the machine, lift the coolant pump from the base. Fill with coolant as
necessary.
Levelling
The Mini Mill needs only to be rough-levelled. Fine levelling of the base will not affect the cutting perfor-
mance of the Mini Mill and is not necessary. Use a machinists level placed on the mill table while rough-
levelling the machine.
MAINTENANCE
Spindle
The spindle needs no extra lubrication during normal use. The spindle is lubricated through the Lube Panel
(see Operators Manual) as part of normal machine operation.
OPTIONS
Floppy Drive
Located on the side of the control pendant, the floppy drive allows easy uploading of machining programs
using standard PC floppy discs. You can download to disc for backup storage or DNC directly off the disc.
BT Tooling
Your Mini Mill can be reconfigured to use your existing inventory of BT tooling, if you prefer.
4th-Axis
Boost productivity with a fully integrated Haas 4th-axis Rotary Table.
Coolant Pump
Supply coolant to your machine with an auxiliary coolant pump. This improves tool life and allows higher
cutting speeds.
