• Keep the intake tube at a maximum vertical slope so that the tube drains completely between
samples.
Note: If a vertical slope is not possible or if the tube is pressurized, disable the liquid detector. Calibrate the
sample volume manually.
• Make sure that the intake tube is not pinched.
Figure 7 Plumbing—Standard liquid detector
Figure 8 Plumbing—Non-contacting liquid detector
14 English
