Table 2 Setup menu
Variable Description
SAMPLE
LABEL
Shows a second menu, Sample Text menu. Under this menu,
set the following items:
• SAMPLE LABEL “SAMPLE NAME”—The user-input name for
samples. The sample labels limit is 10 characters. For each
sample label, there is an auto-counter extension that increments
up to 500. This extension is reset to one every time a new
sample label is programmed, re-entered or exceeds a count of
500.
• REMARKS—User-input remarks for any additional sample
labeling, as necessary. These optional remarks become part of
the record of any completed samples. Records retrieved from
the sample buffer can have their remarks reviewed and re-
edited as necessary. The sample remarks limit is 10 characters
on any of 3 lines. Any existing remarks show on printed sample
reports.
MODE Sampling method (BOTTLE or ONLINE or FILTER)
If BOTTLE mode is selected or re-entered, a second screen is
shown and it allows the following variable to be set.
• PURGE VOL—Volume of fluid that flows through the
instrument to purge any contamination before samples are
taken (15–30 ml).
If ONLINE mode is selected or re-entered, a second screen is
shown and it allows the following variable to be set.
• NUM SAMPLES—Numbers of samples that run during the
sampling period (1–500).
• HOLD TIME—Time delay from the end of a sample to the start
of the next sample. If set for 00:00, a minimum 5-second hold
time is set (hh:mm).
• PURGE VOL—The volume of fluid that flows through the
hydraulic hose and unit to purge any contamination before
samples are taken. The longer the hydraulic hose, the greater
the purge volume must be (15–999 ml).
STD Controls the standard format to show the sample results
(ISO(C), ISO, NAS(C), NAS, NAV(C), NAV, SAE(C), SAE, MIL,
P/10 ml or P/1 ml).
Table 2 Setup menu (continued)
Variable Description
VOL Volume of fluid that runs 3 times during a sample
(Volume/RUN). The BOTTLE mode sampling is limited (5, 10 or
20 ml per RUN).
FLOW Sets the flow rate selections between 15 and 50 ml/min or
AUTO. The AUTO mode automatically uses the optimum flow
rate for the current sample conditions.
PRINT Enables or disables the printer so that it does not automatically
print at the end of a sample. The SETUP option prints the
current instrument setup (ENBL, DSBL or SETUP).
CONTRAST Use the navigation keys to control the display contrast.
Table 3 Screen: PG 2
Variable Description
LANG Shows the language used in the operation and control of the
instrument (English, French, German, Span and Ital).
VISC Controls the units that show the viscosity (cSt, mm2/s or SUS).
TEMP Shows the temperature units (°C or °F).
PRESS Shows the pressure units (BAR or PSI).
DISPL Controls the brightness of the background: light background (Normal)
or dark background (Reversed) (NORM or REV).
BKLT Controls the back light on the LCD display. If AUTO is selected, the
back light turns off after 5 minutes of inactivity (ON, OFF or AUTO).
BEEP Controls audio feedback of the beeper when a key is pushed (KEY or
DSBL).
BSAVE Battery save feature. If enabled, the instrument automatically turns off
after 15 minutes of no activity (Idle state) ((ENBL (Enabled) or DSBL
(Disabled)).
English 11
