Installation
W A R N I N G
Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the
document.
Unpack the instrument
Remove all items from the shipping container and inspect for damage. If any items are missing or
damaged, contact the manufacturer. Refer to Figure 1.
Figure 1 MET ONE 3400 components
1 3400 Series Particle Counter 8 Extension tube for isokinetic probe
2 Rechargeable battery (280-120-2024) 9 Zero count filter
3 AC-to-DC power supply (280-300-5000) 10 RS485 connector assembly
4 Power cord (US) 11 USB Flash drive
5 Power cord (EU) 12 Intake cleaning brush
6 Thermal paper rolls for printer (2x) 13 Wireless antenna for Wi-Fi
7 Isokinetic probe 14 Stylus for touchscreen interface
Wiring safety information
W A R N I N G
Electrocution hazard. Make sure that there is easy access to the local power disconnect.
8 English
