Hach QbD1200 AutoSampler User Manual

Figure 1 Product overview
1 Arm 8 Sample probe
2 Rinse station 9 Power indicator light
3 Stripper plate 10 Calibration standard holder
4 Mechanical Z-drive 11 System suitability holders
5 Sample tube (from the analyzer) 12 Sample positions (1 to 64)
6 Tube holders 13 Sample tray
7 Needle sleeve 14 Rinse station drain tube
6 English

Hach QbD1200 AutoSampler Specifications

General

Brand	Hach
Model	QbD1200 AutoSampler
Category	Laboratory Equipment
Language	English
