2.3 Product components
Make sure that all components have been received. Refer to Product components on page 6. If any
items are missing or damaged, contact the manufacturer or a sales representative immediately.
Figure 2 Product components
1 Module connector 4 Label with wiring information
2 Profibus module 5 Screwdriver, 2-mm wide blade
3 Hardware for shield connection to the controller
enclosure
Section 3 Installation
D A N G E R
Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the
document.
D A N G E R
Electrocution hazard. Remove power from the instrument before this procedure is started.
D A N G E R
Electrocution hazard. High voltage wiring for the controller is conducted behind the high voltage
barrier in the controller enclosure. The barrier must remain in place unless a qualified installation
technician is installing wiring for power, alarms, or relays.
W A R N I N G
Electrical shock hazard. Externally connected equipment must have an applicable country safety
standard assessment.
N O T I C E
Make sure that the equipment is connected to the instrument in accordance with local, regional and national
requirements.
6 English
