Figure 1 Product overview
1 Sample compartment lid 6 Power connection
2 Touch screen display 7 USB port
3 Sample cell holder 8 Power button
4 Lamp cover 9 USB port
5 Air purge
Product components
Make sure that all components have been received. Refer to Figure 2. If any items are missing or
damaged, contact the manufacturer or a sales representative immediately.
English
7
