Buttons function explanation:
When LCD screen in submenu,press it to go back to main window
When LCD screen in main menu,press it to go into the submenu.
When the LCD screen stay in state No.5,6 and 7,Long press 5s the button to make the data
settable(data flashing)
Press it to increase the setting value (in state NO.5,6 and
7).Once LCD screen go into the submenu, by pressing
to
change to last state. eg . If LCD screen in state No,3,you press
ĀUPāthen change to state No.2
but
ton at the same time, the
controller reset to factory
default value.
total charge and
discharge Ah data show
zero.
Press it to reduce the setting value(in state No.5,6 and 7).Once
LCD screen go into the submenu, by pressing
tate .eg. If LCD screen in state No.2 you press
ĀDOWNāthen change to state No.3 .
Notes: 1.If without any operation, no ,matter the LCD screen in which state, it shall
go back to main window which displays the battery voltage.
2.The LCD screen shall be off after 30s, you can affect it by press any button.
3.Only when the LCD screen in main window, the load button can ON/OFF the
DC load.
4.Press the up and down button at same time 5s, when the LCD flash then to
reset the MPPT controller.
Features:
●With maximum power point tracker(MPPT)
●Automatic recognition of system voltage (12/24Vor 48V)
●Input voltage range from 22-60V/30-90V/70-150V
