Hadex MPPT Series User Manual

remote controller is optional.
Operation with optional remote display
Optionally, all models of the MPPT solar controller series maybe operated with a remote display.
Technical specifications
For features and intensity of current, please observe the respective type plate of your device!
Model
MPPT-10A,MPPT-20A,MPPT-30A,MPPT-40A,MPPT-50A,MPTT-60A
Working voltage of the battery
12/24V DC or 48V DC
Module voltage
22-60V/30-90V/70-150V
Max.module/charge current:
10A/20A/30A/40A/50A/60A (type-dependent)
Battery types
All 12V or 24V or 48V rechargeable lead-acid batteries (open,
AGM,
gel)
Own consumption, active
30-50mA
Constant voltage charge
14.6V (14-15V settable)/29.2V (28-30V settable)/58.4V(56-60V
settable)
Low disconnect voltage
11V(10.4-11.4V settable)/22V(20.8-22.8V
settable)/44V(41.6
-45.6V settable)
Low reconnect voltage
12.8V(12.2-13.2Vsettable)/25.6(24-26.4V
settable)/51.2V(48.8
-52.8V settable)
Protection type
IP20
Cross section of terminal
Up to 16m
΃
Environment protection note
At the end of its useful life, this product must not be disposed of together with normal household
waste, but has to be dropped off at a collection center for the recycling of electrical and
electronic devices. This is indicated by the symbol on the product, one the instruction , manual or
on the packaging.
The materials of which this product is made are recyclable pursuant to their labeling. With the
reuse, the recycling of the materials or other forms of scrap usage you are making an important
contribution to the protection of the environment. Please ask your local administration office for
