Eclipse Installation, Commissioning & Operating Manual Approved Document Ref: UI-ECL-01 Issue 8.0
23
SETUP & PROGRAMMING
2 1 3 4
Dependency mode Twin Wire detector compatibility
If using dependency mode, Eclipse panels are designed to work with the following conventional detectors:-
• Apollo Series 65
• Apollo Orbis
• Hochiki CDX
• Nittan Evolution Conventional
However, if also using However, if also using Twin WireTwin Wire mode the panels are optimised for use with Apollo Series 65 heads & mode the panels are optimised for use with Apollo Series 65 heads &
45681-206 Sav-Wire bases.45681-206 Sav-Wire bases.
In order for the other three detector types; Apollo Orbis, Hochiki CDX & Nittan Evolution Conventional to In order for the other three detector types; Apollo Orbis, Hochiki CDX & Nittan Evolution Conventional to
be used with their relevant Sav-Wire bases the above compatibility mode must be switched on.be used with their relevant Sav-Wire bases the above compatibility mode must be switched on.
Enter the code: 2 - 1 - 3 - 4. Zone 1 re LED will pulse. Pressing the ENTER button will illuminate zone 1 Enter the code: 2 - 1 - 3 - 4. Zone 1 re LED will pulse. Pressing the ENTER button will illuminate zone 1
Fault/Disabled/Test LED indicating that the compatibility mode is set to on,
Pressing the ENTER button again will toggle the compatibility mode on & off, indicated by the zone 1 Pressing the ENTER button again will toggle the compatibility mode on & off, indicated by the zone 1 Fault/
Disabled/Test LED.
When nished, press and hold Button 1 (Disable Mode) for 3 seconds or alternatively wait approx 10
seconds and the panel will save the settings and revert back to Level 3 access mode.
Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’.
N.B.N.B.
The above setting is only relevant if you are using The above setting is only relevant if you are using Dependency mode & Twin Wire Dependency mode & Twin Wire
modemode but but NOTNOT using Apollo Series 65 detectors. using Apollo Series 65 detectors.
