Häfele dialock DTSH User Manual

Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
59
English
Installation Instructions
Fig. 40
Do not trap cable!
Vertically align external module so that the 4.
guide pins of the external module engage in the
holes.
Slide external module towards door leaf until it 5.
is lying flat against it. (Fig. 40)
If the external module does not lie flat against the
door:
ð Check drill holes and remove wood debris if
necessary.
The external module is now installed.
