Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
67
English
Installation Instructions
Do not throw batteries in the household waste!
ð Dispose of batteries in an environmentally friendly way, e.g. using a
municipal collection point.
The following steps are required to change the batteries:
The batteries are located in the internal module of the Dialock DTSH door
terminal.
Loosen the grub screw of lever handle aperture part at the inside of the 1.
door using an Allen key.
Pull lever handle aperture part from inner square spindle.2.
Loosen screw from underside of internal module.3.
Remove hood of internal module.4.
Remove old batteries.5.
Insert new batteries into battery holder as quickly as possible. 6.
Ensure that the polarity is correct (see figure 43, page 60)!
Re-attach hood of internal module and tighten screw on underside of 7.
internal module.
Mount lever handle aperture part to inner square spindle and tighten 8.
grub screw using Allen key.
