Hafler PRO5000 User Manual

PRO 5000 FUNCTIONAL BLOCK DIAGRAM
TEMPERATURE
SENSORS
-1
FAN
SPEED
CONTROL
RELAY/
RELAY
\
TIMER
KICKOUT
/’ OFFSET ’
DETECTOR
OUTPUT
SIGNAL
DETECTOR
c
’ --, , ; LIGHT
lo’ s’G
DESIGNATOR PART DESCRIPTION
T201 Transformer
DB201 Diode Bridge
F201
10A Fuse
SW201 Power Switch
SW202 Grounding Switch
C201, C202
Capacitor 20,000
C203 Capacitor .01 (UL approved)
C204 Capacitor .01
TS201 Inrush Limiter
J201 (J203) Binding Post, Black
J202 (J204)
Binding Post, Red
CLIP
> DETECTOR <
CHASSIS PARTS LIST
PART #
TT-PRO5000
SSH-609
FS-010
SWH-144
SWH-103
CER-209
CD-103A
CD-103/20
SSH-618
CCH-1 10B
CCH-1 1OR
-6-
