hager EGN100AU Quick Start Guide

11
On the home screen, tap the device icon and then
device settings.
The time switch implements the "AND" logical operator between all steps in the same program.
1 Tap to open the Date and Time drop-down menu.
2 Slide the Activate special mode button to the
"on" position.
3 Select the output(s) concerned.
1 2
7. The "AND" logical operator (EGN100AU/200AU/400AU)
For example, on the screen below we want to:
• switch on the light when the brightness is below 100 lux, at 6 am, AND at sunset (8:25 pm) = ON
and
• switch o the light when the brightness is above 100 lux, at sunrise (6:32 am) AND at 11:00 pm = OFF
AND
AND
AND
AND
=
ON
=
OFF
