"DALI Gateway C00Cx2" software
Object table
Seite 24 von 130
Function: DALI monitoring
Object Function Name Type DP type Flag
211
Message DALI voltage failure 1-bit 1.005 C, -, T, (R)
1
Description: 1-bit object for reporting a mains voltage failure at the DALI Gateway.
(mains voltage available = 0, mains voltage failure = 1)
Function: DALI monitoring
Object Function Name Type DP type Flag
212
Message DALI short-circuit 1-bit 1.005 C, -, T, R
1
Description: 1-bit object for reporting a short-circuit in the DALI line.
(no short-circuit = 0, short-circuit = 1)
Function: Central function
Object Function Name Type DP type Flag
213
Switching Central function 1-bit 1.001 C, W, – (R)
1
Description: 1-bit object for the central switching of assigned DALI groups. The polarity can be
parameterized.
Function: Manual control
Object Function Name Type DP type Flag
214
Disable Manual control 1-bit 1.003 C, W, – (R)
1
Description: 1-bit object for disabling the keys for manual control on the device. The polarity can be
parameterized.
Function: Manual control
Object Function Name Type DP type Flag
215
Status Manual control 1-bit 1.002 C, -, T, (R)
1
Description: 1-bit object for the status transmission of manual control. The object is "0", when
manual control is deactivated (bus mode). The object is "1", when manual control is
activated. The user can determine whether the temporary or the permanent manual
control will be displayed as status information.
1
Each communication object can be read-out. The readout requires the setting of the R flag.
